The flagship. The giant slayer. The best tonearm we have ever made. Available in 9" and 10".
Every TA-AF tonearm is built to order. Please allow 3-4 weeks for delivery.
What makes the TA-AF series special?
All Korf tonearms are a clean sheet rethink of what a tonearm should be. The TA-AF series takes our priorities to the max: quality of motion, rigidity, low energy storage, signal integrity, stability and longevity.
For the motion, we use aerospace-grade, zero stiction flexure bearings in the horizontal axis. For the vertical axis, we use full ceramic silicon nitride bearings. Nothing comes close for lower starting torque, and for the quietness too.
Korf Audio is the world's only maker of fully ceramic headshells. So it's only natural that we have extended the use of ceramics to the armtube too.
At the same mass, alumina ceramic arm tube is almost twice as strong assteel. This means it's 6x stronger than a similar aluminium tube, or 4x stronger than titanium one
We use "camera finished" brass parts for even more rigidity and precision
Even the wiring is improved: we use super lightweight (but 100% covering) copper shielding over Cardas Clear Litz wires.
How does this benefit you? You will get everything Korf tonearms are known for: unmatched clarity, holographic imaging, real life dynamics, true tonality, sparkling highs and a really deep bass. Only more so. Expect to be drawn into music like never before. And don't be surprised if you find yourself rediscovering your albums all over again.
Discover more
What is included with your tonearm:
Depending on your choice, the JIS/Linn-type mount...
All our mounts are clamping for tightest plinth attachment possible.
...or the SME-type mount, or both
The mounts include DIN 912 screws (M3x20, M3x35), washers and nuts
Simple and effective alignment gauge
Precise alignment gauge to easily set up your cartridge exactly right in minutes.
All the adjustment tools you need
Hex keys to mount your tonearm, adjust VTA, azimuth, etc. Might look a bit different to above.
If you are mounting the tonearm on a wooden plinth, suitable wood screws should be sourced separately.
Specifications
Pivoting gimbal tonearms with fixed headshell;TA-AF9;TA-AF10
Effective length;229 mm;245 mm
Pivot to spindle distance;214 mm;230 mm
Offset angle;22°
Effective mass;21 g
Horizontal axis bearing;Flexure pivot
Vertical axis bearings;Ceramic rolling bearings
Armtube material;Alumina ceramic
Headshell material;Alumina ceramic
Balance type;Static
Minimum cartridge mass;5 g
Maximum cartridge mass;15 g
Maximum cartridge mass with an included additional counterweight;25 g
Cable connector;5 pin MDIN, male
Internal wiring; 6N OCC Litz
Mounting types;JIS/Linn (min. Ø28 mm hole), SME
Mass without cartridge and mounting collar, max;500 g
