If you are mounting the tonearm on a wooden plinth, suitable wood screws should be sourced separately.
Specifications
Pivoting 9" gimbal tonearm with fixed headshell
Effective length;229 mm
Pivot to spindle distance;214 mm
Offset angle;22°
Effective mass;19 g
Horizontal axis bearing;Flexure pivot
Vertical axis bearings;Ceramic hybrid rolling bearings
Armtube material;Stainless steel
Headshell material;Alumina ceramic
Balance type;Static
Minimum cartridge mass;5 g
Maximum cartridge mass;15 g
Maximum cartridge mass with an optional additional counterweight;25 g
Cable connector;5 pin MDIN, male
Internal wiring; OCC Litz
Mounting types;JIS/Linn (min. Ø28 mm hole), SME
Mass without cartridge and mounting collar, max;350 g
What Makes Korf Tonearms Special?
The Korf tonearms are a clean sheet rethink of what a tonearm should be. We focused on our audio priorities: quality of motion, rigidity, low energy storage, signal integrity, stability and longevity.
Stainless steel arm tube is 3x stronger than aluminium, 2x stronger than titanium
There is a lot more—click the button below to discover!
You will immediately hear the sonic benefit: Korf tonearms offer unmatched clarity, holographic imaging, real life dynamics, true tonality, sparkling highs and a really deep bass.
